| 印刷宽度 |
500mm |
600mm |
700mm |
800mm |
1000mm |
1200mm |
1400mm |
1600mm |
| Printing width |
| 承印材料 |
PVC:35~70μm、OPP:20~70μm、BOPP:18~60μm、PE:35~100μm、 |
| Printing material |
NY:20~50μm、PET:12~60μm、CPP：20~60μm、纸张：20~150g/m2 |
| 印刷颜色 |
任意颜色+2个专色 at your own choice+ 2 special color |
| Printing color |
| 印刷长度 |
7.5"～40"(190mm~1000mm)/7.5"～50"(190mm～1270mm) |
| Printing length |
| 起落版方式 |
油压 Pneumatic press control |
| Printing plate lifting system |
| 机械速度 |
150m/min |
| Machanical speed |
| 印刷速度 |
10～120m/min |
| Printing speed |
| 套印精度 |
纵向Longitude:±0.15mm 横向Transverse:±0.15mm |
| Register precision |
| 收/放卷直径 |
φ800mm |
| Rewinder/Unwinder DIA |
|
|
|
|
|
|
|
|
|
|
| 印刷宽度 Printing width |
500mm |
600mm |
700mm |
800mm |
|
|
|
|
| 承印物宽度 Material feeding width |
600mm |
700mm |
800mm |
900mm |
|
|
|
|
| 主马达 Master motor |
5.5Kw |
5.5Kw |
7.5Kw |
7.5Kw |
|
|
|
|
| 收料马达 Rewinder motor |
2.2Kw |
2.2Kw |
2.2Kw |
2.2Kw |
|
|
|
|
| 电热 Electrical heater |
18Kw |
18Kw |
22Kw |
22Kw |
|
|
|
|
| 电热送风机 Blower of heater |
3Kw |
3Kw |
3Kw |
3Kw |
|
|
|
|
| 冷却风机 Blower of nature wind |
1.1Kw |
1.1Kw |
1.1Kw |
1.1Kw |
|
|
|
|
| 行墨马达 Inking motor |
370W |
370W |
370W |
370W |
|
|
|
|
| 主变频器 Master frequency converter |
5.5Kw |
5.5Kw |
7.5Kw |
7.5Kw |
|
|
|
|
| 磁粉制动器 Powder brakes |
5Kg |
5Kg |
5Kg |
5Kg |
|
|
|
|
| 张力检测 Tension sensor |
2~30Kg |
2~30Kg |
2~30Kg |
2~30Kg |
|
|
|
|
| 总功率 Master power |
30Kw |
30Kw |
36Kw |
36Kw |
|
|
|
|
| 净重量 Net Weight |
7550Kg |
785 0Kg |
8200Kg |
9700Kg |
|
|
|
|
| 机械尺寸（长×宽×高）Dimension(L×W×H） |
4.8×1.75×3.75m |
4.8×1.9×3.75m |
4.9×2.0×3.8m |
4.9×2.3×3.8m |
|
|
|
|
| |
|
|
|
|
|
|
|
|
|
| 印刷宽度 Printing width |
1000mm |
1200mm |
1400mm |
1600mm |
|
|
|
|
| 承印物宽度 Material feeding width |
1100mm |
1300mm |
1500mm |
1700mm |
|
|
|
|
| 主马达 Master motor |
11Kw |
11Kw |
15Kw |
15Kw |
|
|
|
|
| 收料马达 Rewinder motor |
3Kw |
3Kw |
3Kw |
3Kw |
|
|
|
|
| 电热 Electrical heater |
30Kw |
30Kw |
38Kw |
38Kw |
|
|
|
|
| 电热送风机 Blower of heater |
5Kw |
5Kw |
5Kw |
5Kw |
|
|
|
|
| 冷却风机 Blower of nature wind |
1.5Kw |
1.5Kw |
1.5Kw |
1.5Kw |
|
|
|
|
| 行墨马达 Inking motor |
750W |
750W |
750W |
750W |
|
|
|
|
| 主变频器 Master frequency converter |
11Kw |
11Kw |
15Kw |
15Kw |
|
|
|
|
| 磁粉制动器 Powder brakes |
10Kg |
10Kg |
10Kg |
10Kg |
|
|
|
|
| 张力检测 Tension sensor |
3~50Kg |
3~50Kg |
3~50Kg |
3~50Kg |
|
|
|
|
| 总功率 Master power |
50Kw |
50Kw |
62Kw |
62Kw |
|
|
|
|
| 净重量 Net Weight |
10300Kg |
10800K |
11300Kg |
11800Kg |
|
|
|
|
| 机械尺寸（长×宽×高）Dimension(L×W×H) |
5.0×2.5×3.85m |
5.0×2.8×3.85m |
5.2×3.0×3.9m |
5.2×3.2×3.9m |
